Features

Connected

The MOTOTRBO XiR P6600i Series is a family of DMR-standard digital radios that delivers operations-critical voice communications. With support for basic trunking as well as legacy analogue technology, you can keep your organization connected as it grows.

Efficient

With new noise cancellation technology and enhanced clarity, the XiR P6600i Series delivers excellent audio quality to make your workplace communications clearly intelligible. The latest energy technology provides the battery option which delivers up to 28 hours of battery life for 3-shift working, and the optional IMPRES Over-the-Air Battery Management tool helps you maximise battery lifetime. An improved receiver boosts range, allowing you to reach further than ever.

Safe

The XiR P6600i Series is designed to improve safety in your organization, with the rapid response capability of instant push-to-talk communications. Even if a worker is unresponsive, you can remotely activate the radio to check that your worker is safe. Radios can be remotely disabled if they are misplaced. New HazLoc models are available for use in areas where flammable or explosive materials are present.

specifications

	No Keypad (NKP) Model
Model Number	XiR P6600i
Band	VHF	350	UHF
Frequency	136-174 MHz	350-400 MHz	403-527 MHz
High Power Output	5 W	4W	4 W
Low Power Output	1 W	1W	1 W
Channel Spacing		12.5, 25 kHz
Channel Capacity	16
Dimensions (H x W x D), Radio + Standard 1600 mAh Battery	122 x 56 x 36 mm
Weight, Radio + Standard 1600 mAh Battery	264 g
Dimensions (H x W x D), Radio + Slim 2050 mAh Battery	122 x 56 x 36 mm
Weight, Radio + Slim 2050 mAh Battery	270 g
Dimensions (H x W x D), Radio + High Capacity 3000 mAh Battery	122 x 56 x 42 mm
Weight, Radio + High Capacity 3000 mAh Battery	292 g
Digital / Analogue Battery Life1, Standard 1600 mAh Battery	16.0 / 11.5 hrs	15.0 / 11.5 hrs
Digital / Analogue Battery Life1, Slim 2050 mAh Battery	19.5 / 14 hrs	18.5 / 14 hrs
Digital / Analogue Battery Life1, High Capacity 3000 mAh Battery	28.5 / 21 hrs	27.5 / 21 hrs
Power Supply (Nominal)	7.5 V
