Motorola MTX900 The Power Tool for Contact and Control

Audio Technology

As with any radios, sound quality is critical for effective communications. Motorola’s MTX900 series can be heard in almost any environment because of LLE and noise cancelling microphone.

Wideband and Programmable Channel Spacing [12.5/20/25 kHz

The wideband technology and programmable channel spacing of 12.5/20/25 kHz offer flexibility & easy migration should channel spacing requirement expand.

Automatic Multiple Site Selection (AMSS}

The AMSS feature extends communications beyond the reach of a single trunked site. In a system where multiple trunking sites are used to extend coverage; the AMSS will automatically switch the radio to a different site when the current site signal becomes too weak Thus ensuring users continuous radio communications.

Emergency Alarm*

An emergency function is provided to alert the dispatcher. This function is activated by pushing an easily accessible orange button on the top of the radio. These calls are processed by the trunking system with the highest priority to ensure that they get through as quickly as possible.

Selective Radio Inhibit

In situations when the radios have been stolen or are missing the selective radio inhibit feature will enable the dispatcher to remotely disable the radios for greater security.

Talkgroup Scan

Provides effortless scanning combination of talkgroups and conventional channels for messages, and monitoring of channels in a multiple system environment

Dual Mode Capability

Enables user the convenience of selecting either both trunked or conventional operation providing maximum systems flexibility.

Dust and Humidity

Protection provided via environment resistant housing exceeding

MIL STD 810 C/D/E and TIA/EIA603

Specifications

Type	Handheld
Dimensions	137mm x 57.5mm x 37.5mm
Frequency Range	136-174MHz 403-470MHz , 800MHz
Storage Channel	16 Talkgroups
Talk Range	5-8km
color	black
Battery life	8 hours (High Power), 11 Hours (Low Power)
Output power	1 – 5W / 1 – 4W ( VHF, UHF), 1 – 2.5W (800MHz)
Weight ( including standard battery )	420g
Display	NO
Keyboard	NO
