Icom GM600 Transceiver

Icom GM600 Transceiver Icom GM600 3505 fixed VHF GMDSS transceiver, RF output power 25W, A-class differential scanning calorimeter, large and high contrast 4.3-inch TFT color LCD display, day and night mode, 10W audio output power, with external speakers. Large 4.3 inch color TFT LCD Color…

Icom GM600 Transceiver


Icom GM600  3505 fixed VHF GMDSS transceiver, RF output power 25W, A-class differential scanning calorimeter, large and high contrast 4.3-inch TFT color LCD display, day and night mode, 10W audio output power, with external speakers.

  • Large 4.3 inch color TFT LCD
  • Color TFT-LCD provides user-friendly icon and display design. The improved font can quickly recognize alphanumeric characters. You can choose between day and night modes according to lighting conditions.
  • Intuitive user interface
  • The menu items display user-friendly icons and can be navigated via the main dial knob or the up and down keys. Commonly used functions are arranged at the bottom of the display and can be switched with the left and right keys.
  • High-quality front speakers
  • The built-in 57mm diameter front speaker is waterproof, providing clear audio from bass to treble. When connected with external speakers, GM600 provides a powerful 10W audio output, even in noisy places, the sound can be heard clearly.
Frequency Range
Tx
Rx
CH70
156.025–161.600 MHz
156.025–162.000 MHz
156.525 MHz
Usable channels INT channels
Type of emission 16K0G3E (FM), 16K0G2B (DSC)
Power supply requirement
Tx (at 25W output)
Rx (Maximum audio)
13.8 V DC (GM600)
24 V DC (21.6–31.2 V)
12 V DC (10.8–15.6 V)
Current drain (with PS-310 #01)
Tx (at 25W output)
Rx (Maximum audio)
 (approximately)
3.3A (with PS-310 #01)
2.0A (with PS-310 #01)
Operating temperature range –15°C to +55°C
Antenna Impedance 50Ω (SO-239)
Weight (approximately) 1600g
